Ventless Hood System Replacement Parts
23
Figure 3. Right Side Cabinet Assembly – Continued
Table 3. Right Side Cabinet Assembly Parts List
ITEM # PART # QTY DESCRIPTION
1 S0097 1 SWITCH, VACUUM 371
2 S0098 1 SWITCH, VACUUM 371
3 S0099 1 SWITCH, VACUUM 371
4 S0101 1 SWITCH, VACUUM 371
5 SCR289 8 SCREW, 10-32 X 1/2 PHIL TRUSS
6 NUT051 8 NUT, 10-24 HEX ZINC PLTD
7 WSH090 8 LOCK WASHER, SWITCH MOUNTING
8 PL0004 1 PILOT LIGHT, ROUND 250V
9 S0073 2 SWITCH, PUSHBUTTON MICRO
10 S0310 1 SWITCH, FLUSH GREEN PUSH
11 S0307 1 SWITCH, NO BLOCK GE P9B10VN
12 S0311 1 SWITCH, EXTENDED RED PUSH
13 S0306 1 SWITCH, NC BLOCK GE P9B01VN
To Next Page
