BKI FH-28 - Accessories

Ventless Hood System Replacement Parts
26
Figure 6. Fire Detection System Assembly Parts
1 2 3 4
5 6 7 8
9 10
Table 6. Fire Detection System Assembly Parts List
ITEM # PART # QTY DESCRIPTION
1 FA37110400 1 CONDUIT, 1/2 EMT 1.375"
2 FB37110600 1 CONDUIT, 1/2 EMT 11.625"
3 FB37139302 1 BRACKET,FH A+ CONT.HEAD MOUNT
4 FE0017 2 PULLEY, FIRE SYS FH/LFH
5 FE0041 1 CONTROL BOX,A+,(CO2) BADGER
6 FE0042 1 MICROSWITCH KIT, A+ CONTROL
7 FT0288 1 COMPRESSION FITTING 1/2-1/2NPT
8 FT0554 1 COMPRESSION FITTING BRASS
9 MB37139500 1 CONDUIT,EMT 31"FH
10 MB37139600 1 TUBING,1/4"COPPER,24"FH
Accessories
PART # QTY DESCRIPTION PICTURE
FI0024
Or
FI0025
1 FILTER, FIBERGLASS FH
Or
FILTER, HIGH CARBON FH
FB37144203 1 APPLIANCE STOP
