7
ENGLISH
(Original instructions)
Problem Possible cause Possible solution
Battery pack will not
charge.
Charger not plugged
in.
Surrounding air
temperature too hot or
too cold.
Plug charger into a work-
ing outlet.
Move charger and battery
pack to a surrounding air
temperature of above 40
degrees F (45ºC) or below
105 degrees F (+40.5ºC)
Unit shuts off
abruptly.
Battery pack has
reached its maximum
thermal limit.
Out of charge. (To
maximize the life of
the battery pack it is
designed to shutoff
abruptly when the
charge is depleted
Allow battery pack to cool
down.
Place on charger
and allow to charge.
Maintenance
Your BLACK+DECKER tool has been designed to operate
over a long period of time with a minimum of maintenance.
Continuous satisfactory operation depends upon proper tool
care and regular cleaning.
Your charger does not require any maintenance apart from
regular cleaning.
Warning! Before performing any maintenance on the tool,
remove the battery from the tool. Unplug the charger before
cleaning it.
u Regularly clean the ventilation slots in your tool and
charger using a soft brush or dry cloth.
u Regularly clean the motor housing using a damp cloth.
Do not use any abrasive or solvent-based cleaner.
u Regularly open the chuck and tap it to remove any dust
from the interior.
Protecting the environment
Z
Separate collection. This product must not be
disposed of with normal household waste.
Should you nd one day that your BLACK+DECKER product
needs replacement, or if it is of no further use to you, do not
dispose of it with household waste. Make this product avail-
able for separate collection.
z
Separate collection of used products and
packaging allows materials to be recycled and
used again.
Re-use of recycled materials helps prevent en-
vironmental pollution and reduces the demand
for raw materials.
Local regulations may provide for separate collection of elec-
trical products from the household, at municipal waste sites or
by the retailer when you purchase a new product.
BLACK+DECKER provides a facility for the collection and re-
cycling of BLACK+DECKER products once they have reached
the end of their working life. To take advantage of this service
please return your product to any authorised repair agent who
will collect them on our behalf.
You can check the location of your nearest authorised repair
agent by contacting your local BLACK+DECKER ofce at the
address indicated in this manual. Alternatively, a list of author-
ised BLACK+DECKER repair agents and full details of our
after-sales service and contacts are available on the Internet
at: www.2helpU.com
Batteries
Z
There are no user servicable parts inside.
u At the end of your products life return the whole unit to
your service agent or to a local recycling station to have
the battery recycled. Do not throw the unit out with house-
hold waste.
Technical data
BDCDD12
Voltage V
DC
10.8
No-load speed Min
-1
0-550rpm
Max. torque Nm 12.5/26
Chuck capacity mm
1-10
Max Drilling capacity
Steel/wood mm 10/25
Weight kg
0.98
Charger 90589867
Input voltage V
AC
230
Output voltage V
DC
10.8
Current mA
200mA
Approx. charge time Hours
8
