5
A,SJOW-A,SJTW-A.orSJTOW-A.Makesureyourextensioncordisingoodcondition.When
using an extension cord, be sure to use one heavy enough to carry the current your product will
draw. An undersized cord will cause a drop in line voltage resulting in loss of power and
overheating. The table shows the correct size to use depending on cord length and nameplate
ampere rating. If in doubt, use the next heavier gauge. The smaller the gauge number, the
heavier the cord. If the extension will be used outside, the cord must be suitable for outdoor
work. The letters “WA” on the cord jacket indicate that the cord is suitable for outdoor use.
Minimum Gauge for Cord Sets
Volts Total Length of Cord in Feet
120V 0-25 26-50 51-100 101-150
(0-7,6m)(7,6-15,2m)(15,2-30,4m)(30,4-45,7m)
Ampere Rating
More Not more American Wire Gauge
Than Than
6 - 10 18 16 14 12
