Figure 7 Dual-monitor consoles with serial and audio extension
CPU
Keyboard and mouse for
Local console connect to
spare USB ports or hub.
ACU4222A Local Unit
Takes video and USB signals
from CPU. Also provides video
outputs for Local console.
ACU4222A Remote Unit
Video, audio/serial output and
four USB ports for extended
devices: keyboard, mouse,
graphics tablet, USB drive.
Local Console
Dua
l monitor console.
Remote Console
Dual monitor console.
Monitor 2 is serial touch screen.
