Black Stone 1605 - Illustrated Parts List

ENGLISH
ENGLISH
| Owner’s Manual
ILLUSTRATED PARTS LIST
1 Body (1 piece) 2 Griddle top
(1 piece)
3 Side shelf
(1 piece)
4 Control
knobs (2 pieces)
5 Grease cup
(1 piece)
6 Bottom tray
(1 piece)
7 Right
handle (1 piece)
8 Wheels
(2 pieces)
9 Propane
tank bar (1 piece)
10 M6x60 Bolt
(1 piece)
11 M6x38 Bolt
(4 pieces)
12 Large
thumb screws
(2 pieces)
13 Small
thumb screws
(2 pieces)
14 Propane
tank hanger
(1 piece)
15 Propane
tank support
(1 piece)
16 M6x12 Bolts
(4 Pieces)
17 Flange nuts
(9 Pieces)
TOOLS NEEDED: Phillips head screwdriver
& Adjustable wrench
NOT INCLUDED:
20 lb LP gas tank & AA Battery
Model 1605
05
Assembly Guide
