Black Stone 6000 - Page 10

ENGLISH
BLACKSTONEPRODUCTS.COM/SUPPORT
OWNER’S MANUAL | ASSEMBLY GUIDE MODEL: 
STEP 26
Note: DO NOT tighten the bolts completely until all the bolts
and washers are properly installed.
Use fourteen (14) [CC] bolts, fourteen (14) [FF] flat washers, and
fourteen (14) [JJ] sealant washers to attach roof panels {M1}, {M2},
{M5}, and {M7} to cross beams {D3} and {D4}.
Use sixteen (16) [CC] bolts, fourteen (14) [FF] flat washers, and
sixteen (16) [JJ] sealant washers to attach roof panels {M1}, {M2}, {M5},
and {M7} to roof top ribs {H1} and {H2}.
STEP 27
Use four (4) [CC] bolts, four (4) [FF] flat washers, and four (4)
[JJ] sealant washers to attach roof panel 4 {M4} to the roof top ribs.
STEP 28
Use six (6) [CC] bolts, six (6) [FF] flat washers, and six
(6) [JJ] sealant washers to attach one (1) roof panel 6 {M6} to the
roof top ribs.
STEP 29
Use ten (10) [CC] bolts, ten (10) [FF] flat washers, and ten (10)
[JJ] sealant washers to attach roof panel 8 {M8} to the roof top ribs.
M1
M5
M5
M2
M7
[FF]
[JJ]
[FF]
[JJ]
[CC] × 30
[FF] × 30
[JJ] × 30
[FF]
[JJ]
M4
[FF]
[JJ]
[CC] × 4
[FF] × 4
[JJ] × 4
M6
[FF]
[JJ]
[FF]
[JJ]
[CC] × 6
[FF] × 6
[JJ] × 6
M8
[FF]
[JJ]
[CC] × 10
[FF] × 10
[JJ] × 10
[FF]
[JJ]

