OWNER’S MANUAL | ASSEMBLY GUIDE MODEL:
STEP 18
Use four (4) [AA] bolts
and four (4) [FF] flat washers
to attach shelf 2 {K2} to the {L1}
shelf braces.
STEP 19
Use four (4) [AA] bolts
and four (4) [FF] flat washers
to attach shelf 3 {K3} to the {L1}
shelf braces.
STEP 20
Use four (4) [AA] bolts
and four (4) [FF] flat washers
to attach shelf 4 {K4} to your
preferred {J3} side panel.
STEP 21
Note: DO NOT tighten
the bolts completely until all the
bolts and washers are properly
installed.
Use three (3) [CC] bolts and
three (3) [FF] flat washers to
attach the post 9 {A9} assembly
to side shelf 5 {K5}.
Optional right side
installation
K2
[AA] × 4
[FF] × 4
Optional right side
installation
[AA] × 4
[FF] × 4
K4
[CC] × 3
[FF] × 3
K5
A9
Optional right side
installation
K3
[FF] × 4
Optional left side
installation
Optional left side
installation
Optional left side
installation
Optional left side
installation
