Mini Converter SDI to HDMI 4K
43
Cable
EQ
Cable
EQ
Cable
EQ
Cable
EQ
SDI IN 2
SDI IN 1
SDI
Wrapper
Central
Processor and
Firmware
HDMI
Transmitter
SDI IN 4
SDI IN 3
USB
HDMI Out
5. MINI-B USB PORT
Connects to the Converter Utility software via your Mac OS X or Windows computer. The Mini Converter’s
internal software is also updated using the USB port.
6. HDMI
HDMI type A video output.
7. POWER +12V
12 volt power supply input.
Mini Converter SDI to HDMI 4K Block Diagram
SDI IN 1
SDI IN 2
SDI IN 3
SDI IN 4
HDMI OUT
SDI to HDMI 4K
6
5
7
1
2
3
4
