Mini Converter SDI to HDMI 4K
42
SDI IN 1
SDI IN 2
SDI IN 3
SDI IN 4
HDMI OUT
SDI to HDMI 4K
Blackmagic Mini Converter SDI to HDMI 4K
Connect single link, dual link and quad link SDI 4K to the latest Ultra HD projectors and televisions that
support 4K over a single HDMI link. You can also convert any of the following inputs to HDMI:
 SD-SDI to SDTV.
 HD-SDI to HDTV.
 Single link 3G-SDI
 Single link 6G-SDI
 Dual link HD-SDI
 Dual link 3G-SDI 4K to Ultra HD 4K.
 Quad link HD-SDI 4K to Ultra HD 4K.
If the HDMI output detects an HD monitor or HDTV, the output signal is automatically downconverted. Only
use inputs 1 and 2 with a valid dual link signal.
Connectors
Supported formats are listed under each SDI input:
1. SDI IN 1
 SD/HD-SDI
 Single link 3G-SDI
 Single link 6G-SDI
 Dual link HD-SDI channel A
 Dual link 3G-SDI 4K channel A
 Quad link HD-SDI 4K channel A
2. SDI IN 2
 Dual link HD-SDI channel B
 Dual link 3G-SDI 4K channel B
 Quad link HD-SDI 4K channel B
3. SDI IN 3
 Quad link HD-SDI 4K channel C
4. SDI IN 4
 Quad link HD-SDI 4K channel D
6
5
7
1
2
3
4
Mini Converter SDI to HDMI 4K
