Mini Converter SDI Multiplex 4K
41
Cable
EQ
Cable
EQ
Cable
EQ
Cable
EQ
SDI IN 2
SDI IN 1
Central
Processor and
Firmware
Cable
Driver
Cable
Driver
Cable
Driver
Cable
Driver
SDI IN 4
SDI IN 3
SDI OUT 2
SDI OUT 1
SDI OUT 4
SDI OUT 3
USB
Mini Converter SDI Multiplex 4K Block Diagram
