22Connecting to a Network
Direct Ethernet Connection Diagram
You can connect the Ethernet port of a computer directly to a unit without needing a network
switch. Additional units can be daisy-chained to each other so you don’t have to run multiple
cables back to a network switch. Power must be supplied to all units.
Ethernet Network Switch Connection Diagram
If you want to connect several units to your studio’s existing network, you only need to connect
one unit to the network switch. The rest can be daisy-chained to each other so you don’t have
to run multiple cables back to a network switch. Power must be supplied to all units.
SmartScope 4KDuo
SmartScope 4KDuo
Network Switch
Ethernet
Client
Computers
To Next Page
