Blackmagicdesign Teranex Mini Series User Manual

Contents
Teranex Mini Converters
Getting Started 5
Plugging in Power 5
Plugging in Video 5
Plugging in Audio 5
Installing Administration Software 6
Installing Blackmagic Teranex Setup 6
Installing Teranex Mini Smart Panel 7
Smart Panel Features 8
Changing Settings 9
Changing Settings using Switches 9
Changing Settings using Blackmagic
Teranex Setup 9
Changing Settings using Teranex Mini Smart Panel 10
Changing Network Settings 11
Changing network settings using
Blackmagic Teranex Setup 11
Changing network settings using Teranex
Mini Smart Panel 11
Teranex Mini - SDI to HDMI 12G 12
Teranex Mini - HDMI to SDI 12G 16
Teranex Mini - SDI to Analog 12G 19
Teranex Mini - Analog to SDI 12G 23
Teranex Mini - SDI to Audio 12G 26
Teranex Mini - Audio to SDI 12G 30
Teranex Mini Rack Shelf 34
Help 34
Warranty 35

Blackmagicdesign Teranex Mini Series Specifications

General

Category	Media Converter
Reclocking	Yes
Color Space Conversion	Yes
Frame Rate Conversion	Yes
Audio Embedding/De-embedding	Yes
Video Inputs	SDI, HDMI
Video Outputs	SDI, HDMI
Audio Inputs	Embedded in SDI/HDMI
Audio Outputs	Embedded in SDI/HDMI
Updates and Configuration	Via USB
Power Consumption	16W
Supported Resolutions	Up to 2160p60
Multi Rate Support	Yes. Auto detection of SD, HD or 6G-SDI. Simultaneous 4K/6G-SDI and HD-SDI output.
