14
ENGLISH
(Original instructions)
Problem Possible solution
Mower doesn’t run when
bail handle is activated.
Check to make sure mower is properly plugged
in and that the button on switch box is being
completely depressed before pulling the bail
handle.
Release bail handle to turn mower off. Remove
battery pack, turn mower over and check that
blade is free to turn.
Check that the battery cavity is free of debris
and is connected properly.
Has battery been fully charged? Press state of
charge button.
Motor stops while mowing. Release bail handle to turn mower off. Remove
battery pack Turn mower over and check that
blade is free to turn.
Raise cutting height of wheels to highest posi-
tion and start mower.
Check that the battery cavity is free of debris
and is connected properly
Has battery been fully charged? Press state of
charge button
Avoid overloading the mower. Slow down the
cutting pace, or raise the cut height.
Mower runs but cutting
performance is unsatisfac-
tory,
Release bail handle to turn mower off. Unplug
mower. Turn mower over and check:
u Blade for sharpness - Keep blade sharp.
u Deck and discharge chute for clogging.
Wheel height adjustment may be set too low for
grass condition. Raise cutting height.
Mower is too hard to push. Release bail handle to turn mower off. Unplug
mower. Raise cutting height to reduce deck
drag on grass. Check each wheel for free
rotation
Mower is abnormally noisy
and vibrates.
Release bail handle to turn mower off. remove
battery pack. Turn mower on side and check
blade to ensure it has not been bent or
damaged. If blade is damaged, replace with
a BLACK+DECKER replacement blade. If
the underside of the deck is damaged, return
mower to a BLACK+DECKER Authorized
service center.
If there is no visible damage to the blade and
the mower still vibrates:
u Release bail handle to turn mower off.
u Remove battery pack.
u Disassemble entire blade assembly as
described in the “Removing and installing
blade” section.
u Remove any debris and clean each piece.
u Replace each piece as described in the
“Removing and installing blade” section.
If mower still vibrates, return the mower to
an authorized BLACK+DECKER authorized
service center.
Battery charger LEDs
not on.
Check plug connection.
Replace charger.
Mower not picking up
clippings with bag.
Chute clogged. Release bail handle to turn
mower off. Remove battery pack. Clear chute of
grass clippings.
Raise cutting height of wheels to shorten length
of the cut.
Bag full. Empty bag more often.
Protecting the environment
Z
Separate collection. Products and batteries
marked with this symbol must not be disposed of
with normal household waste.
Products and batteries contain materials that can be
recovered or recycled, reducing demand for raw materials.
Please recycle electrical products and batteries according to
local provisions. Further information is available at
www.2helpU.com
Technical data
BCMW3318 BCMW3336
Voltage
Vdc 18V 36V
No-Load Speed
min
-1
3800RPM 3800RPM
Weight
kg
15 15
Blade length
cm 33 33
Batteries Chargers (minutes)
Cat# Vdc Ah Weight Kg
Cat# 90590287* N517388* BDC1A BDC2A BDC2A36
Amps 400mA 1A 1A 2A 1.35A
BL1518 18 1.5 0.38 BL1518 225 90 90 45 X
BL1518ST 18 1.5 0.38 BL1518ST 225 90 90 45 X
BL2018 18 2.0 0.39 BL2018 300 120 120 60 X
BL2018ST 18 2.0 0.39 BL2018ST 300 120 120 60 X
BL2518 18 2.5 0.43 BL2518 380 150 150 75 X
BL4018 18 4.0 0.64 BL4018 600 240 240 120 X
BL5018 18 5.0 0.7 BL5018 750 300 300 135 X
BL20362 36 2.0 0.64 BL20362 X X X X 90
BL2536 36 2.5 0.68 BL2536 X X X X 110
BL1554 18/54 1.5 1.08 BL1554 225 90 90 45 X
BL2554 18/54 2.5 1.2 BL2554 380 150 150 75 X
Hand/arm weighted vibration value:
= <2.5 m/s
2
, uncertainty (K) = 1.5m/s
2
.
L
PA
(sound preasure) 74.5 dB(A)
uncertainty (K) = 2.5 dB(A)
L
WA
(sound power) 86 dB(A)
uncertainty (K) = 1.5 dB(A)
EC declaration of conformity
MACHINERY DIRECTIVE
OUTDOOR NOISE DIRECTIVE
%
BCMW3318, BCMW3336 lawn mower
Black & Decker declares that these products described under
"technical data" are in compliance with:
2006/42/EC, EN 60335-1:2012 + A11:2014,
EN 60335-2-77:2010
