ENGLISH
11
BATTERIES
BLACK+DECKER batteries can be recharged many
times. At the end of their useful life, discard batteries
with due care for our environment:
• Run the battery down completely, then remove it
from the tool.
• NiCd, NiMH and Li-Ion batteries are recyclable. Take them to
any authorized repair agent or a local recycling station.
TECHNICAL DATA
LITHIUM ION CORDLESS
SCREWDRIVER
BD40 ION
Voltage
4 V
MAX*
Speed .../min (rpm) 320
Max hard/soft
torque
in-lb (Nm) 44.3 - 22.1 (5 - 2.5)
Torque adjustment 1 - 5
Max screw diameter in (mm) 1/4" (6.35)
Charging cable connection Micro-USB
CHARGER (included in BD40K27)
Input voltage V 100 - 240
Frequency Hz 50 - 60
Output voltage
5 V
Current A 1
Charge time hr 1.5
BATTERY
Battery Integrated
Voltage
4 V
MAX*
Capacity Ah 1.5
Type Lithium-Ion
* Maximum initial battery cell voltage (measured without
a workload) is 4 volts. Nominal voltage is 3.6 V.
