7
ENGLISH
(Original instructions)
6. Charger connector
7. Flashlight
8. Flashlight button
Charging tool (g.A)
The battery needs to be charged before rst use and whenev-
er it fails to produce sufcient power on jobs that were easily
done before. The battery may become warm while charging;
this is normal and does not indicate a problem.
Warning! Only use the charger provided to charge the tool.
u To charge the battery, insert the charger plug (6a) into the
connector (6).
u Plug in the charger.
u Leave the tool connected to the charger for 10 hours.
The charger may hum and become warm while charging; this
is normal and does not indicate a problem.
Warning! Do not charge the battery at ambient temperatures
below 10 °C or above 40 °C. Recommended charging tem-
perature: approx. 24 °C.
Fitting and removing a screwdriver bit or socket
(g. B)
Warning! Make certain the tool is locked to prevent switch
actuation before installing or removing accessories.
u To t a screwdriver bit (9), push it into the bit holder (3)
until it locates.
u To remove a screwdriver bit, pull it straight from the bit
holder.
Use
Warning! Let the tool work at its own pace. Do not overload.
Using the ashlight (g. C)
u Press the ashlight button (8) to operate the ashlight (7).
u Press ashlight button (8) again to turn off the ashlight
(7).
Switching on and off (g. D)
u To operate the tool, press and hold the trigger switch (1).
u To switch the tool off, release the trigger switch (1).
Selecting the direction of rotation (g. E)
For tightening screws and drilling pilot holes, use forward
(clockwise) rotation. For loosening screws or removing a
jammed drill bit, use reverse (counterclockwise) rotation.
u To select forward rotation, push the forward/reverse slider
(2) to the right.
u To select reverse rotation, push the forward/reverse slider
(2) to the left.
u To lock the tool, set the forward/reverse slider (2) into the
centre position.
Adjusting the handle (g. F)
For optimum versatility, the handle (5) can be set to three
different positions.
u Press the handle adjustment button (4).
u Move the handle (5) into the desired position.
u Release the handle adjustment button (4).
Maintenance
Your BLACK+DECKER tool has been designed to operate
over a long period of time with a minimum of maintenance.
Continuous satisfactory operation depends upon proper tool
care and regular cleaning.
Your charger does not require any maintenance apart from
regular cleaning.
Warning! Before performing any maintenance on the tool,
remove the battery from the tool. Unplug the charger before
cleaning it.
u Regularly clean the ventilation slots in your tool and
charger using a soft brush or dry cloth.
u Regularly clean the motor housing using a damp cloth. Do
not use any abrasive or solvent-based cleaner.
u Regularly tap bit holder to remove any dust from the
interior.
Protecting the environment
Z
Separate collection. Products and batteries
marked with this symbol must not be disposed of
with normal household waste.
Products and batteries contain materials that can be recov-
ered or recycled reducing the demand for raw materials.
Please recycle electrical products and batteries according to
local provisions. Further information is available at
www.2helpU.com
Technical data
BDCSFL20 H2
Voltage V
DC
3.6
No-load speed Min
-1
180
Max. torque (PTI Rating) Nm 5.5
Battery Type Li-Ion
Battery capacity Ah 1.5
Weight kg 0.35
