Blackridge BRC95 - Parts Diagram

18
PARTS DIAGRAM
Part Description Qty SMG Part No.
5 Cylinder Head 1 95 BRC95CH
19 Oil Breather 1 95 BRC95OB
21 Sight Glass Seal 1 95 BRC95OLSG
22 Sight Glass 1 95 BRC95OLSG
27 Air Filter 1 95 BRC95AF
28 Exhaust Elbow 1 95 BRC95EE
35 Safety Valve 1 95 BRC95SPV
36 Pressure Switch 1 95 BRC95PS
37 Connector 1 95 BRC95PTC
38 Regulator Single Tap 1 95 BRC95OPRS
39 Outlet Tap 2 95 BRC95OT
40 Unloading Tube Nut 2 95 BRC95UT
41 Unloading Tube 1 95 BRC95UT
42 Pressure Gauge Large 1 95 BRC95TPG
Part Description Qty SMG Part No.
43 Pressure Gauge Small 1 95 BRC95OPG
44 One Way Valve 1 95 BRC95OWV
50 Rubber Handle Grip 1 95 BRC95TH
52 Drain Tap 1 95 BRC95DT
53 Cushion Foot 2 95 BRC95RS
54 Nut 2 95 BRC95RS
55 Washer 2 95 BRC95RS
56 Screw 2 95 BRC95RS
57 Bolt 2 95 BRC95WHB
58 Wheel 2 95 BRC95WH
59 Screw Nut 2 95 BRC95WHB
60 Exhaust Tube 1 95 BRC95ET
61 Exhaust Tube Nut 2 95 BRC95ET
