Blade 200 SRX - Transmitter Setup Table

6
EN
Transmitter
Model Type
Setup / Channel Assignments Reversing Setup Flight Modes Dual Rates
Hgh Rate
Low Rate Other Settings
MLP6DSM N/A
DIP Switches: 1, 2, 4, 5, 6, 7, 9, and 10 = OFF 3 and 8 = ON
N/A
CH 5 Pos 0 = Beginner
Default
100% Fixed
70% Fixed
CH 5 Pos 1 = Intermediate CH 5 Pos 2 = Experienced
DX4e (New) w/ 3 Position Switch
N/A MIX=NOR All channels = NORM
CH 5 Pos 0 = Beginner
Ail/Ele/Rud
100% Fixed
70% Fixed
CH 5 Pos 1 = Intermediate CH 5 Pos 2 = Experienced
DX5e (New) w/ 3 Position Switch
N/A MIX=NOR All channels = NORM
CH 5 Pos 0 = Beginner
Ail/Ele/Rud
100% Fixed
70% Fixed
CH 5 Pos 1 = Intermediate CH 5 Pos 2 = Experienced
DX7/7SE Acro
Gear=INH Flap=GEAR Trainer=Aux1
AUX1 = REV Throttle Travel = 85% Low, 100% Full
Gyro Switch Pos 0 = Beginner
Ail D/R switch = Ail D/R Ele D/R switch = Ail D/R Rud D/R switch = Ail D/R
100% 70%
Timer Count Down 08:00 Tone Start: Throttle Out Pos: 25%
Gyro Switch Pos 1 = Intermediate Gyro Switch Pos 2 = Experienced
DX8 Acro
Flap=INH Trainer=AUX1 Gear=INH F Mode=Gear
AUX1 = REV All Others = NORM Throttle Travel = 85% Low, 100% Full
Switch B Pos 0 = Beginner
Ail D/R switch = Ail D/R Ele D/R switch = Ail D/R Rud D/R switch = Ail D/R
100% 70%
Timer Count Down 08:00 Tone Start: Throttle Out Pos: 25%
Switch B Pos 1 = Intermediate Switch B Pos 2 = Experienced
DX9/DX18 Acro
Channel Input Confi g 5 GEAR = B 6 AUX 1 = I
AUX1=REV Throttle Travel = 85% Low, 100% Full
Switch B Pos 0 = Beginner
Ail D/R switch = Ail D/R Ele D/R switch = Ail D/R Rud D/R switch = Ail D/R
100% 70%
Timer Count Down 08:00 Tone Start: Throttle Out
Switch B Pos 1 = Intermediate Switch B Pos 2 = Experienced
Transmitter Setup Table
