14
REGULATION
7) PROCEDURE FOR REGULATING THE MINIMUM
CAPACITY OF THE BURNERS
The procedure for acquiring the minimum capacities allows the modification of the
minimum capacity programmed, adapting every burner to the characteristics of
the gas distribution network to which the hob is connected.
The procedure is activated by pressing the + and - buttons of burner 3 together
with the + and - buttons of burner 1 continuously for 3 seconds, with all the
burners switched off (standby).
The activation of the regulation procedure is indicated on the display with the
word “MIN”. At this point it is possible to select the burner to be regulated using
buttons 12 and 13 (- and + of the clock programming), after confirmation with the
Clock button (11), the burner selected ignites at the minimum and the capacity
can be increased or decreased to the minimum level using the + and - buttons of
the burner. During the display regulation procedure, the flame display levels will
show the indication ‘-’ if the minimum level programmed corresponds with the
factory setting, and the indication will change ^ or v in flashing mode, indicating a
higher or lower capacity than that programmed.
To confirm the minimum capacity required, it is necessary to press the Clock
button (11). The word “MIN” will continue to be present and none of the leds will
flash. At this point it is possible to press the Clock button (11) to exit the
procedure, or press buttons 12 and 13 to select another burner and programme
its minimum capacity. The minimum capacity levels will then be acquired and
memorised by the device, and will be used in the normal use of the hob (see
fig. 9).
The regulation operations listed below are reserved to qualified fitters only.
After carrying out any regulation or pre-regulation operations, any seals
must be replaced by the technician.
The regulation of primary air to our burners is not necessary.
A duplicate Data Label is supplied to adhere in an accessible area next to
the hotplate.
REGULATION AND TRANSFORMATION
