20
FIG. 16
MAINTENANCE
POWER CABLE TYPES AND SECTIONS
TYPE OF HOB TYPE OF POWER CABLE MONOPHASE
Gas hob H05 RR - F Section 3 x 0.75 mm
2
ATTENTION!!!
If the power supply cable is replaced, the installer should leave the ground wire longer than the phase
conductors (fig. 16) and comply with the recommendations given in paragraph 6.
CAUTION:
Polarity must be observed.
Brown is active.
Blue is neutral.
To cooktop will fail to function properly if the polarity is not observed.
