3
Table of contents
Inspection comments 2
1. Introduction 4
2. Machine description 4
3. Safety 5
3.1 Work area safety 5
3.2 Electrical safety 5
3.3 Personal safety 6
3.4 Machine safety 6
3.5 Shot / steel blasting safety 7
3.6 Dust collector safety 7
3.7 Maintenance safety 7
3.8 Transport safety 7
3.9 Signs on the machine 9
4. Before operation 10
4.1 Checkpoints of power supply 10
4.2 Checkpoints of the machine 10
4.3 Drive control 10
4.4 Control box 11
4.5 Transport 12
4.6 Manual moving of the machine 12
Driving without connected drive motor 12
4.7 Connecting the drive motor to the traction wheel 13
4.8 Driving with connected drive motor 14
4.9 Blast wheel 14
4.10 The abrasive valve 14
4.11 Separator 14
4.12 Abrasive sealing 15
4.13 Changing the transmission ratio (option) 16
5. Operation 17
5.1 Before switch on 17
5.2 Checking & Correcting the turning direction 17
5.3 Switching the machine on 17
5.4 Operation 18
5.5 Switching the machine off 18
5.6 The blast pattern 19
5.7 Adjusting the blast pattern 19
6. Maintenance 20
6.1 Changing the tune-up kit 22
6.2 Changing the liners 23
6.3 The V-belt 26
6.4 V-belt mounting 26
6.5 V-belt tension 26
6.6 The chain drive 27
7. Selection of abrasive 28
8. Troubleshooting 29
9. Technical data 31
