Blastrac EBE 350 E - Spare Parts List

Operating Instructions EBE 350 E
Spare parts
10.1 Spare parts
Blast housing and seals
Item Part no. Description Qty.
1 - Bolt M10x50 + 2 x Nut M10 3
2 350-1059-SE Locating plate outer 1
3 350-1054-SE Front skirt outer 1
4 - Front seal angle (part of blast housing) 1
5 350-1053-SE Front skirt intermediate 1
6 350-1058-SE Front locating plate inner 1
7 350-1057-SE Front skirt fixing plate 1
8 350-1052-SE Front skirt inner 1
9 350-9006-E Blast housing cabinet 1
10 350-2010-SEV Front wheel castor complete 1
11 350-1021-SE Side seal spring plate 2
12 350-1020-SE Side seal (set of 2) 1
13 350-1060-SE Side skirt (set of 2) 1
14 350-1061-SE Side skirt fixing plate 2
15 350-1050-SE Side brush (set of 2) 1
16 - Bolt M6x16 + washer + spring lock washer 6
17 350-1045-SE Back brush 1
18 350-1047-SE Back brush skirt 1
19 350-1115 Top liner cover 1
