EBE 350 E Operating Instructions
Spare parts
Fan Unit
Item Part no. Description Qty.
1 350-3055-S Fan motor 1.5 kW 1
2 350-9030 Fan housing plate (top) 1
3 350-1085 SE Fan impeller 1
4 350-1090-SE Fan housing 1
5 350-9025 Fan housing plate (bottom) 1
6 035-9035 Fan ring 1
7 035-1125 Fan housing seal 1
Fig. 10.4
7
