Operating Instructions EBE 350 E
Spare parts
Control handle and blast wheel drive
Item Part no. Description Qty. Hz.
1 350-9110-UNI Control box UNI 1
2 350-3006-E Electric drive system AC 1
3 350-9085-E Handle complete 1
4 350-3020-SEP Blastmotor 11kW 1
5 350-2170 Belt pulley (50Hz) 1 50Hz
350-2180 Belt pulley (60Hz) 1 60Hz
6 222-2171 Taperlock bush 1 50/60Hz
7 350-2430-S Blastmotor belt 1
8 350-9255-S Belt guard complete 1
9 - Bolt M10x25 + washer Ø40 1
10 222-2290 Blastwheel shaft taperl. bush (60Hz) 1 60Hz
11 350-2175 Belt pulley (50Hz) 1 50Hz
350-2345 Belt pulley (60Hz) 1 60Hz
12+13 350-9027-SE Belt guard back plates 1
14 350-2464-SEVU Blast wheel shaft spacer 8mm 1 50Hz
350-2463-SEVU Blast wheel shaft spacer 32mm 1 60Hz
15 350-2451-SEV Blastwheel bearing house complete 1
16 350-9007-SEVU Blast motor mount plate 1
8
