EBE 350 E Operating Instructions
General
Rear seal system:
The rear seal system comprises of one back brush and a back brush
skirt, which are located inside the rear seal box. They are clamped in
place by locking screws.
To replace the rear seals:
1 Tip the machine backwards on the floor.
2 Unscrew the locking screws and pull out the worn rear seals.
3 Fit a new back brush and back brush skirt into the rear seal
box and tighten the locking screws.
4 Lower the machine, fit the side seals and check that both axles
of the side seal spring plates have come out at the top of the
seal boxes, to be sure that the side seals are positioned
correctly.
5 Put the machine back on its wheels and commence work.
Fig. 3.11
1 Rear seal angle (machine)
2 Back brush skirt
3 Back brush
15
