Blatchford Orion3 - Device Construction; Principal Parts Identification

938375V2APK1/1-0321
5
Principal Parts:
• Frame (CF Composite)
• Chassis (Aluminium Alloy)
• Pyramid (Stainless Steel)
• Hydraulic/Pneumatic Cylinder (Various materials including Aluminium Alloy, Stainless Steel,
hydraulic oil, motors and PCBs)
• Knee Pad/Battery Case (Polyurethane)
• Batteries (Lithium-ion)
Component Identication
3 Construction
Hydraulic/
Pneumatic
Cylinder
Battery
On/O
Switch
[+], [-]
Buttons
and LED
Magnetic
Charging
Terminal
Knee
prosthesis
Knee Pad/
Battery Case
Chassis
