BLAUBERG Calm - Fan Operation Guidelines; Operating Rules and Conditions

Dimensions [mm]
Table 3. Overall dimensions
Model
Calm 100
OPERATION RULES
The fan is rated for connection to 220...240 V / 50 Hz power mains and
is designed for continuous operation always connected to power mains.
The air motion direction in the system must match the pointer on the
fan casing.
The fan is rated for operation at ambient temperature from +1 °C up
to +45 °C.
The fan does not require grounding.
4
Fig. 1
Calm 125
Calm 150
Calm Max 150
a
158
182
214
b
136
158
190
c
81
91
98
d
99
124
148
e
26
27
32
B H
L1
L
D
