BLAUBERG Sileo - Overall Dimensions and Operation Rules; Operation Rules

Dimensions [mm]
Table 3. Overall dimensions
Model
Sileo 100
OPERATION RULES
The fan is rated for connection to 220...240 V / 50 Hz power mains and
is designed for continuous operation always connected to power mains.
The air motion direction in the system must match the pointer on the
fan casing.
The fan is rated for operation at ambient temperature from +1 °C up
to +45 °C.
The fan does not require grounding.
24
Fig. 1
Sileo 125
Sileo 150
Sileo Max 150
a
158
182
214
b
136
158
190
c
81
91
98
d
99
124
148
e
26
27
32
