Blaupunkt Arrifana 08C User Manual

www.blaupunkt.com
Arrifana 08C
13
OPERATING FROM THE CONTROL PANEL
The control panel enables you to manage all the main functions of the appliance, but to fully
exploit its potential, you must use the remote control unit.
TURNING THE APPLIANCE ON
 Plug into the mains socket.
Two lines appear on the display indicating that the appliance is in standby.
 Press the button until the appliance comes on. The last function active when it was
turned off will appear.
 Never turn the air conditioner off by unplugging from the mains. Always press the
button , then wait for a few minutes before unplugging. This allows the appliance to
perform a cycle of checks to verify operation.
COOL MODE
Ideal for hot muggy weather when you need to air conditioning and dehumidify the room.
To set this mode correctly:
 Press the " " button a number of times until the " " symbol appears.
 Select the target temperature by pressing the " " or " " button until the corresponding
value is displayed.
 Select the required fan speed by pressing the " " button.

Blaupunkt Arrifana 08C Specifications

General

Type	Monobloc mobile air conditioner
Noise level	55 dB
LED indicators	Yes
Number of speeds	3
Water tank capacity	1 L
Airflow (high speed)	350 m³/h
Cooling capacity (max)	8000 BTU/h
Air conditioner functions	Cooling, Dehumidifying, Ventilating
Cooling temperature range	18 - 32 °C
Cooling capacity in watts (max)	2330 W
Cooling capacity in watts (nominal)	- W
Cooling energy efficiency (EER, W/W)	2.61
Heating energy efficiency (COP, W/W)	-
Display type	LED
Product color	Grey, White
Current	4.1 A
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (cooling)	890 W
Energy efficiency class (cooling)	A
Hourly energy consumption (cooling)	- kWh

Weight and Dimensions

Depth	770 mm
Width	283 mm
Height	506 mm
Weight	25000 g
