Blaupunkt Arrifana 08C User Manual

www.blaupunkt.com
Arrifana 08C
28
CLEANING
Before cleaning or maintenance, turn the appliance off by pressing the button on the
control panel or ON/OFF button on remote control, wait for a few minutes then unplug from
the mains socket.
CLEANING THE CABINET
You should clean the appliance with a slightly damp cloth then dry with a dry cloth.
 Never wash the air conditioner with water. It could be dangerous.
 Never use petrol, alcohol or solvents to clean the appliance.
 Never spray insecticide liquids or similar.
CLEANING THE AIR FILTERS
To keep your air conditioner working efficiently, you should clean the filter every week of
operation.
The filters are housed in the intake grille (fig. 29).
Use a vacuum cleaner to remove dust accumulations from the filter. If it is very dirty, immerse
in warm water and rinse a number of times. The water should never be hotter than 40°C.
After washing, leave the filter to dry then attach the intake grille to the appliance.

Blaupunkt Arrifana 08C Specifications

General

Type	Monobloc mobile air conditioner
Noise level	55 dB
LED indicators	Yes
Number of speeds	3
Water tank capacity	1 L
Airflow (high speed)	350 m³/h
Cooling capacity (max)	8000 BTU/h
Air conditioner functions	Cooling, Dehumidifying, Ventilating
Cooling temperature range	18 - 32 °C
Cooling capacity in watts (max)	2330 W
Cooling capacity in watts (nominal)	- W
Cooling energy efficiency (EER, W/W)	2.61
Heating energy efficiency (COP, W/W)	-
Display type	LED
Product color	Grey, White
Current	4.1 A
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (cooling)	890 W
Energy efficiency class (cooling)	A
Hourly energy consumption (cooling)	- kWh

Weight and Dimensions

Depth	770 mm
Width	283 mm
Height	506 mm
Weight	25000 g
