CONTINUOUS DRAINAGE (Fig.26)
When operating in HEAT mode*, continuous drain method can also be used to avoid the
trouble of manual drainage.
 Empty the water tank completely.
 Connect one end of the drain hose on the drain outlet, and lead the other end to outdoor or
and place where can be drained freely.
 Turn on the appliance and select HEAT mode*.
When continuous drainage method adopted in HEAT mode*, the water removed from the air
flows out through the drain hose continuously.
NOTE
Please be sure that the height of and section of the drain hose should not be higher than that
of the drain outlet, or the water tank may not be drained (Fig.27 & 28).
"*" means only the heat pump model have this function.

Blaupunkt Arrifana 08C Specifications

General

Type	Monobloc mobile air conditioner
Noise level	55 dB
LED indicators	Yes
Number of speeds	3
Water tank capacity	1 L
Airflow (high speed)	350 m³/h
Cooling capacity (max)	8000 BTU/h
Air conditioner functions	Cooling, Dehumidifying, Ventilating
Cooling temperature range	18 - 32 °C
Cooling capacity in watts (max)	2330 W
Cooling capacity in watts (nominal)	- W
Cooling energy efficiency (EER, W/W)	2.61
Heating energy efficiency (COP, W/W)	-
Display type	LED
Product color	Grey, White
Current	4.1 A
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (cooling)	890 W
Energy efficiency class (cooling)	A
Hourly energy consumption (cooling)	- kWh

Weight and Dimensions

Depth	770 mm
Width	283 mm
Height	506 mm
Weight	25000 g
