Blaupunkt Arrifana 08C User Manual

www.blaupunkt.com
Arrifana 08C
18
REMOTE CONTROL
REMOTE DISPLAY
SMART Mode Indicator LOW FAN SPEED Indicator
COOLING Indicator MIDDLE FAN SPEED Indicator
FAN ONLY OPERATION Indicator HIGH FAN SPEED Indicator
DEHUMIDIFYING Indicator BATTERY Indicator
SLEEP Indicator TIMER ON Indicator
SIGNAL RECEPTION Indicator TIMER OFF Indicator
CLOCK Indicator
 For the remote control to operate correctly the remote handset has to be in line of sight of
receiver (attached to the front of unit below the air vents). There will be no change in the
function of the unit if the remote transmitter handset is not in line of sight of the unit or if
there are any obstacles between the remote control and receiver.
 Each time when there is a change in the function of the unit it will beep which indicates that
the receiver attached to the unit has sensed the button press of the remote.

Blaupunkt Arrifana 08C Specifications

General

Type	Monobloc mobile air conditioner
Noise level	55 dB
LED indicators	Yes
Number of speeds	3
Water tank capacity	1 L
Airflow (high speed)	350 m³/h
Cooling capacity (max)	8000 BTU/h
Air conditioner functions	Cooling, Dehumidifying, Ventilating
Cooling temperature range	18 - 32 °C
Cooling capacity in watts (max)	2330 W
Cooling capacity in watts (nominal)	- W
Cooling energy efficiency (EER, W/W)	2.61
Heating energy efficiency (COP, W/W)	-
Display type	LED
Product color	Grey, White
Current	4.1 A
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (cooling)	890 W
Energy efficiency class (cooling)	A
Hourly energy consumption (cooling)	- kWh

Weight and Dimensions

Depth	770 mm
Width	283 mm
Height	506 mm
Weight	25000 g
