Blaupunkt Arrifana 08C User Manual

www.blaupunkt.com
Arrifana 08C
25
WATER DRAINAGE METHOD
This air conditioner is equipped with the very last MIST technology which means the water
tank nearly never fills, hence, water drainage will generally only be required at the end of the
season (see START-END OF SEASON OPERATIONS).
However, the MIST technology does not operate when the unit is in HEAT mode*. Thus, the
tank may still require emptying in HEAT mode*.
NOTE
As a safety measure, to positively prevent water spillage, the air conditioner is equipped with a
failsafe device, if, the water tank fills. The unit will completely stop, the control panel displays
" " (FULL TANK as mentioned in SELF-DIAGNOSIE), the compressor and fan will not restart
until the tank has been drained.
"*" means only the heat pump model have this function.

Blaupunkt Arrifana 08C Specifications

General

Type	Monobloc mobile air conditioner
Noise level	55 dB
LED indicators	Yes
Number of speeds	3
Water tank capacity	1 L
Airflow (high speed)	350 m³/h
Cooling capacity (max)	8000 BTU/h
Air conditioner functions	Cooling, Dehumidifying, Ventilating
Cooling temperature range	18 - 32 °C
Cooling capacity in watts (max)	2330 W
Cooling capacity in watts (nominal)	- W
Cooling energy efficiency (EER, W/W)	2.61
Heating energy efficiency (COP, W/W)	-
Display type	LED
Product color	Grey, White
Current	4.1 A
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (cooling)	890 W
Energy efficiency class (cooling)	A
Hourly energy consumption (cooling)	- kWh

Weight and Dimensions

Depth	770 mm
Width	283 mm
Height	506 mm
Weight	25000 g
