Blaupunkt EMA 260 User Manual

5
EMA 260
Betriebsanzeige (POWER / PROTECTION)
Grünes Licht:
Endstufe an, regulärer Betriebszustand.
Rotes Licht:
Endstufe ist elektronisch abgeschaltet, da Fehlerfall
vorliegt.
Recycling und Entsorgung
Bitte nutzen Sie zur Entsorgung des Produktes
die zur Verfügung stehenden Rückgabe- und
Sammelsysteme.
Änderungen vorbehalten.
ENGLISH
Warranty
We provide a manufacturer guarantee for our products
bought within the European Union. You can view the
warranty terms at
www.blaupunkt.de or request them
directly from:
Blaupunkt GmbH
Hotline
Robert-Bosch-Str. 200
D-31139 Hildesheim, Germany
Guarantee for the USA
Please read these operating instructions before using
the equipment for the first time.
We provide a manufacturer guarantee for our pro
-
ducts bought within the United States of Ameri
-
ca. The warranty terms can be called up under
www.blaupunkt.usa.com or requested directly from:
Blaupunkt USA
2800 South 25th Av.
Broadview, IL 60155
PH: 800-950-2528
FX: 708-865-5296
EM: blau.tech.support@us.bosch.com
Recommendation:
The performance of an amplifier can only be as good
as its installation. A correct installation increases the
overall performance of your car sound system. The EMA
amplifier should be installed by a trained person. If you
would to install it yourself, please read these installation
instructions very carefully and allow yourself sufficient
time for the installation.
In conclusion, allow us a few words about the topic of
health protection:
During the playback of music in your vehicle, please
consider that continuous sound-pressure levels above
100 dB can lead to permanent damages to the human
ear and even to loss of hearing. Using today's high-perfor
-
mance systems and loudspeaker configurations allows
for reaching sound-pressure levels above 130 dB.
Safety notes
Please observe the following safety notes
during the installation and connection.
-
Disconnect the negative pole of the battery!
Observe the safety notes of the vehicle manufac-
turer.
- When you drill holes, ensure that you do not dam
-
age any vehicle components.
- The cross section of the plus and minus cable may
not be less than 6 mm
2
.
- Use cable glands for holes with sharp edges.
- An incorrect installation can result in malfunctions
of the electronic vehicle systems or your car sound
system.
Installation and connection instructions
With respect to accident safety, the EMA 260 must be
secured in a professional way.
When selecting the installation location, select a dry
location that offers sufficient air circulation for cooling
the amplifier.
The EMA 260 must not be installed on rear shelves, rear
seats or other locations that are open to the front.
The installation location must be suitable to accept the
accompanying screws and provide a firm support.
The amplifier power cable must be fitted with a fuse (25 A) no
more than 30 cm from the battery to protect the vehicle
battery in case of a short circuit between power amplifier
and battery. The fuse of the amplifier protects only the
amplifier, not the vehicle battery.
Use loudspeakers with 2-4  impedance (see table or
installation drawing). Observe the maximum power
handling capacity (music output). Do not connect lou
-
dspeakers to earth, use only the referenced terminals.
Amplifier EMA 260
The amplifier is suitable for connecting a car sound
system with cinch connections.
For the connection to car sound systems with
ISO connection, use Blaupunkt ISO cinch adapters
(7 607 893 093 or 7 607 855 094).
Application options and loudspeaker connection:
Stereo Mode
Max power
2 x 110 Watt / 4  Fig. 4, 5
Mono mode
Max power
1 x 350 Watt / 4  Fig. 6
Stereo Mode
Max power
2 x 160 Watt / 2  Fig. 4, 5
EMA_260_181207.indd 5 08.08.2008 11:45:50 Uhr
