Blaupunkt GTA 470 DSP - Page 50

GTA 470 DSP
50
Fig. 9
OUTPUT
SUBWOOFER REARFRONT
INPUT
L
R
PHASESUBSONIC
SUBWOOFER
X-OVER
0 80Hz 0 180
F/R
SUBSONIC
0 80Hz
SUB dB/Oct
18 24 48
REAR dB/Oct
18 24 48
FRONTdB/Oct
18 24 48
PWR/PRO
REAR
GAIN
5V 200mV
FRONT
GAIN
5V 200mV
X-OVER
50Hz 5kHz
X-OVERREAR
50Hz 5kHz
FULL HI LOW
FRONT
FULL HI LOW
R
E
M
O
T
E
OFF
ON
F
R
SUB COMPRESSOR
F/R COMPRESSOR
F/R SUBSONIC
40Hz 200Hz
GTA RC01
Anschluss • Connection • Raccordement • Conexión • Ligação • Collegamento • Podłączenie •
Připojení • Подключение • Racordare • Cвързване • Priključak • Priklop
