Blaupunkt GTA 470 DSP Installation & Connection Manual

GTA 470 DSP
6
Technische Daten
Quadro-Mode
Max Power
4 x 140 W / 4 Ω Fig. 4, 5
Stereo-Mode
Max Power
2 x 420 W / 4 Ω Fig. 6
Quadro-Mode
Max Power
4 x 200 W / 2 Ω Fig. 4, 5
Quadro-Mode
RMS Power
4 x 70 W / 4 Ω Fig. 4, 5
Stereo-Mode
RMS Power
2 x 200 W / 4 Ω Fig. 6
Quadro-Mode
RMS Power
4 x 100 W / 2 Ω Fig. 4, 5
Frequenzgang 10 Hz – 30 000 Hz
Signal-Rauschabstand > 92 dB @ RMS Power
Signal-Rauschabstand > 75 dB @ 1 W / 1 kHz
Klirrfaktor (RMS) < 0,05 %
Stabilität 2 Ω (4 Ω im Brückenbetrieb)
Eingangs-
emp ndlichkeit
0,2 V – 5 V
Tiefpass lter
(Low-Pass)
50 Hz – 5 000 Hz
Hochpass lter
(High-Pass)
50 Hz – 5 000 Hz
Subsonic-Filter 0 Hz – 80 Hz
Kompressor-Limiter 10 dB
Abmessungen
B x H x T (mm)
B x H x T (")
323 x 54 x 198
12.7 x 2.1 x 7.8
Recycling und Entsorgung
Bitte nutzen Sie zur Entsorgung des Produktes die
zur Verfügung stehenden Rückgabe- und Sammel-
systeme.
Änderungen vorbehalten.
ENGLISH
Warranty
We provide a manufacturer's warranty for products bought
within the European Union. For devices purchased outside
the European Union, the warranty terms issued by our re-
spective responsible domestic agency are valid. The warranty
terms can be called up from www.blaupunkt.com.
Recommendation
The performance of an ampli er can only be as good as
its installation. A correct installation increases the overall
performance of your car sound system. The GTA ampli er
should be installed by a trained person. If you would to install
it yourself, please read these installation instructions very
carefully and allow yourself su cient time for the installation.
In conclusion, allow us a few words about the topic of health
protection:
During the playback of music in your vehicle, please consider
that continuous sound-pressure levels above 100 dB can
lead to permanent damages to the human ear and even to
loss of hearing. Using today's high-performance systems
and loudspeaker con gurations allows for reaching sound-
pressure levels above 130 dB.
Safety notes
Please observe the following safety notes during the instal-
lation and connection.
– Disconnect the negative pole of the battery! Observe the
safety notes of the vehicle manufacturer.
– When you drill holes, ensure that you do not damage any
vehicle components.
– The cross section of the plus and minus cable may not
be less than 6 mm
2
.
– Use cable glands for holes with sharp edges.
– An incorrect installation can result in malfunctions of
the electronic vehicle systems or your car sound system.
Installation and connection instructions
With respect to accident safety, the GTA 470 DSP must be
secured in a professional way.
When selecting the installation location, select a dry location
that o ers su cient air circulation for cooling the ampli er.
The GTA 470 DSP must not be installed on rear shelves, rear
seats or other locations that are open to the front.
The installation surface must be suitable to accept the ac-
companying screws and provide a  rm support.
The ampli er power cable must be  tted with a fuse no more
than 30 cm from the battery to protect the vehicle battery in
case of a short circuit between power ampli er and battery.
The fuse of the ampli er protects only the ampli er, not the
vehicle battery.
Only loudspeakers with 2 - 4 Ω impedance may be used
(see table or installation drawings). Observe the maximum
power handling capacity (music output). Do not connect
loudspeakers to earth, use only the referenced terminals.
