DEVICE OVERVIEW
5.6" and 7"
ON
OSDSRCVIDEO
9
1
2
3
4
5
6
11
10
8
7
1 5.6"/ 7" TFT LCD screen for
headrests
2 On/off switch
3 Key for screen menu display
(OSD menu)
4 Up menu
5 Down menu
6 AV channel setting
(AV1 - AV2 - AV3 - AV4 - AV5)
7 Headphone socket
8 Video input (internal)
9 Connecting cable
: Interface cable
; AV signal converter unit
