29
Aut. antenna +12V
Ampli er +12V
Remote Control +12V
Switched Ext. Supply +12V
max. 200 mA
*
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
C
B
A
1
4
7
10
13
16
19
3
6
9
12
15
18
2
58
11
14
17
20
C-1 C-2 C-3
10 Ampere
AB
1 NC 1 Speaker Out RR+
2 Radio Mute 2 Speaker Out RR–
3 NC 3 Speaker Out RF+
4 Permanent +12V 4 Speaker Out RF–
5 Aut. antenna +12V * 5 Speaker Out LF+
6 Illumination 6 Speaker Out LF–
7 Kl.15/Ignition 7 Speaker Out LR+
8 Ground 8 Speaker Out LR–
C1 C2 C3
1 NC 7 NC 13 Uart Communication RX
2 NC 8 NC 14 Uart Communication TX
3 Line Out GND 9 Radio Mute 15 Battery Connection Fused **
4 Line Out Left 10 Remote Control +12V * 16 Switched Ext. Supply +12V *
5 Line Out Right 11 Remote Control IN 17 Battery GND
6 Line Out +12V * 12 Remote Control GND 18 NC
19 NC
20 NC
** Battery voltage 12V
Installation instructions
