Blendtec Q-SERIES - Page 20

20
FIGURE 2.1 - ABOVE COUNTERTOP: ABC, SMOOTHER
(WITH Q SERIES COMPONENTS)
9.35”
(237.49 mm)
2.59”
(65.78 mm)
22.51”
(571.75 mm)
9.35”
(237.49 mm)
18.41”
(467.62 mm)
9.29”
(235.96 mm)
18,41”
(467.62 mm)
FRONT VIEW
SIDE VIEW
(OPEN ENCLOSURE)
SIDE VIEW
