Blendtec Q-SERIES - Page 22

22
FIGURE 3.1 - IN - COUNTER: ABC, SMOOTHER
(WITH Q SERIES COMPONENTS)
8.00”
(203.2 mm)
3.03”
(77 mm)
14.37”
(365 mm)
8.97”
(227.8 mm)
10.24”
(260 mm)
10.24”
(260 mm)
8.49”
(215.6 mm)
FRONT VIEW
SIDE VIEW
(OPEN ENCLOSURE)
SIDE VIEW
