7
www.blendtec.com
SECTION 3 - BLENDER OVERVIEW
(Refer to Figures 1 and 2)
3.1 BLENDER MOTOR
• Touch Pad: Consists of nine buttons that contain pre-programmed settings for
selective blender control, a pulse button, and two speed control buttons.
• Blender Drive Socket: This is where the jar couples with the motor to turn the blade
assembly.
• LCD Information Center: Indicates status of unit as well as overload or over-tem-
perature conditions.
• Power Unit: This unit is located with the blender motor and contains the machinery
that runs the blender.
3.2 BLENDER JAR ASSEMBLY
The blender jar assembly consists of the blender jar, blade assembly, and lid.
• Jar: Made from a tough durable material to provide maximum efficiency and clear
visibility of blender performance.
• Lid: Flexible rubber lid seals liquids within the jar during blending.
• Blade Assembly: Stainless steel designed to provide fast, consistent blending.
• Power Switch: Located on the back lower-right corner of the motor base cover.
• Power Cord: Located at the back of the motor base cover.
• Motor Base Cover: Houses the power unit in a durable, easy-to-clean
polycarbonate.
NOTE: Filling the blender jar beyond the marked capacity is not recommended.
SECTION 4 - INSTALLATION
1. Place blender on a flat, clean, and dry surface.
2. Make sure a plug outlet is available within four feet of the blender motor.
3. Ensure the unit is turned off before plugging it into a separate 120-volt recep-
tacle.
4. Ensure that blender vents are unobstructed to allow proper cooling during use.
We recommend that surge protection be placed between the receptacle and the
blender motor.
SECTION 5 - CARE AND CLEANING
5.1 AFTER USE CLEANING
1. Add 1 cup of hot water and a drop of liquid dishwashing soap to the blender jar.
2. Place the lid tightly onto the jar. Place the blender jar on the blender base and,
with your hand placed on top of the lid, press the pulse button for 5 seconds.
