G60™ Manual Rev. A Copyright (c) 2011 Blizzard Lighting, LLC
Tech Specs!
Weight & Dimensions
Length 15.8 inches (400 mm)
Width 9.5 inches (240 mm)
Height 18.6 inches (470 mm)
Weight 28 lbs (12.73 kg)
Power
Operating Voltage 110-240VAC, 50-60 Hertz (autoranging)
Fuse 5A 250V (fast-blow)
Power Consumption 160W
Light Source
LED 1x60W Luminus CST-90 LED 50,000 hours
Optical
Beam Angle 15 degrees
Luminous Intensity 27,800 Lux @ 1 m / 6,240 Lux @ 2 m
Gobo Size
25mm outside, 22mm image, 1.2mm max
thickness
Movement Range
Pan 540 degrees
Tilt 263 degrees
Thermal
Max. Operating Temp. 104 degrees F (40 degrees C) ambient
Control
Protocol USITT DMX-512
DMX Channels 15
Input 3-pin XLR Male
Output 3-pin XLR Female
Favorite Color
Blue
Warranty
2-year limited warranty, does not cover mal-
function caused by damage to LED’s.
