DMX Values In-Depth (10-Channel Mode)
Ch. Value What It Does
1 000 <--> 255 Dimmer (0% <--> 100%)
2 000 <--> 255 Red Intensity (0% <--> 100%)
3 000 <--> 255 Green Intensity (0% <--> 100%)
4 000 <--> 255 Blue Intensity (0% <--> 100%)
5 000 <--> 255 Amber Intensity (0% <--> 100%)
6 000 <--> 255 White Intensity (0% <--> 100%)
7 000 <--> 010
011 <--> 255
No Function
Strobe Speed (slow <--> fast)
8
Value What It Does Value What It Does Value What It Does
000 <--> 015
016 <--> 021
022 <--> 027
028 <--> 033
034 <--> 039
040 <--> 045
046 <--> 051
052 <--> 057
058 <--> 063
064 <--> 069
070 <--> 075
Dimming
R
G
B
A
W
R+G
R+B
R+A
R+W
G+B
076 <--> 081
082 <--> 087
088 <--> 093
094 <--> 099
100 <--> 105
106 <--> 111
112 <--> 117
118 <--> 123
124 <--> 129
130 <--> 135
136 <--> 141
G+A
G+W
B+A
B+W
A+W
R+G+B
R+G+A
R+G+W
R+B+A
R+B+W
R+A+W
142 <--> 147
148 <--> 153
154 <--> 159
160 <--> 165
166 <--> 171
172 <--> 177
178 <--> 183
184 <--> 189
190 <--> 195
196 <--> 201
202 <--> 255
G+B+A
G+B+W
G+A+W
B+A+W
R+G+B+A
R+G+B+W
R+G+A+W
R+B+A+W
G+B+A+W
Full ON
Auto Run
9 000 <--> 015
016 <--> 250
251 <--> 255
No Function
Color Fade (slow <--> fast)
Sound Active
10
000 <--> 005
006 <--> 055
056 <--> 105
106 <--> 155
156 <--> 205
206 <--> 255
32-Bit Dimmer
As set in the control menu display
Mode 0 = 8-bit, 256 dimming steps
Mode 1 = 32-bit, 0-25% intensity range
Mode 2 = 32-bit, 0-50% intensity range
Mode 3 = 32-bit, 0-75% intensity range
Mode 4 = 32-bit, full intensity dimming
DMX Values In-Depth (7-Channel Mode)
Ch. Value What It Does
1 000 <--> 255 Dimmer (0% <--> 100%)
2 000 <--> 255 Red Intensity (0% <--> 100%)
3 000 <--> 255 Green Intensity (0% <--> 100%)
4 000 <--> 255 Blue Intensity (0% <--> 100%)
5 000 <--> 255 Amber Intensity (0% <--> 100%)
6 000 <--> 255 White Intensity (0% <--> 100%)
7 000 <--> 010
011 <--> 255
No Function
Strobe Speed (1-20Hz)
