Chapter 3 The device
AudioBlock Bollmannsweg 41 26125 Oldenburg
M o d e l : WFR 7 0 0
W i f i i n t e r n e t / F M rece i v e r
P o w e r R a t i n g : AC 2 3 0 V 50H z
M a x P o w e r C o n s u m p t i o n : 8 0 W
AUX 1
AUX 2
AUX 3
AUX 3
AUX 2
AUX 1
Wi-Fi Antenna
Wi-Fi Antenna
1 2
3
4
5 6
7
8 9 10
1. Power cord inlet : Please ensure that the input cable strain relief
bush is intact and has not been damaged.
2. Warning icons: Please be aware that this unit contains high voltages,
and should not be opened.
3. FM antenna input jack.
4. 2.4G wi-fi antenna input jack (for internet radio).
5. Right speaker output jack.
6. Left speaker output jack.
7. Input source 3.5mm jack for AUX3.
8. Input source RCA jack for AUX2.
9. Input source RCA jack for AUX3.
10. LAN wire input jack(for internet radio).
Rear panel
