blueclean sp116 - Part 2: Installation Instruction; Installation Safety & Signals

Work station series for solar water heating control system
11
Part 2: Installation instruction
Ⅰ General information
1. Safety
Before installing the device, please read this manual carefully. Please note that the installation
must be executed according to relevant technical rules . The installation must be adapted to the
conditions provided by the customer. Damages by improper using or incorrect modification of
installation and construction are on costumer site.
Attention: This manual is for trained personals only!
Note: As faults can never be excluded, we don’t offer a guarantee for the completeness of the
drawings and texts of this manual, they only represent some examples.
2. Input and output signals
1 T1 connector 4
P2 circulation pump connector
2 T2 connector 5
Power plug connector
3 T3 connector 6 Auxiliary heating connector
3.
System demonstration
