BL6-U Parallel Integrated Controller Quick Commissioning User Manual
35
U1~U5 Monitoring Parameters (Cont'd)
Para
No.
Display
Content
Unit
Ref
Page
U4-09
Lock Timer
The current elevator stop timer.
--
--
U4-10

U4-19
Standby Para 1~Standby Para10
Reserve parameters. Some parameter can be given
a meaning when needed.
--
--
U5-00
CtrlSoftWare NO
Show the elevator control software information.
Provide the current software version for factory
maintenance and software upgrading.
--
--
U5-01
DriveCodeVer
Show the drive control software information.
Provide the current software version for factory
maintenance and software upgrading.
--
--
U5-02
CpldEdition
Show base drive control software information.
Provide the current software version for factory
maintenance and software upgrading.
--
--
U3-00 Cabin Signal Content & Definition
Cabin signal
Symbol signal
Cabin terminal No.
Content
C00
IGM1
J3-4
door close 1 input
C01
IKM1
J2-4
door open 1 input
C02
IGM2
J5-4
door close 2 input
C03
IKM2
J4-4
door open 2 input
C04
GMV2
J10-6
door close limit 2 input
C05
KMV2
J10-5
door open limit 2 input
C06
GMV1
J9-3
door close limit 1 input
C07
KMV1
J9-2
door open limit 1 input
C08
SZY
J10-1
Special Use Input
C09
IGMYS
J6-4
door open delay input
C10
SZH
J9-10
Attendant input
C11
--
--
Empty (for Backup use)
C12
SZS
J10-2
Bypass drive input
C13
MZ
J9-6
Full-load input
C14
QZ
J9-8
Light-load input
C15
CZ
J9-5
Over-load input
C16
KZ (50%)
J9-9
50% Full-load (No-load) input
C17
KAB2
J9-7
Door safety plate 2
C18
KAB1
J9-4
Door safety plate 1
U6 Drive Monitoring Parameters List
Para
No.
Display
Content
Unit
U6-00
Power
Rated power class
kW
U6-01
Ref Speed
Reference Speed
RPM
U6-02
Feedback Speed
Feedback Speed
RPM
U6-03
Load
The current load in % of full load
%
U6-04
DC Voltage
DC BUS voltage
V
U6-05
Output Current
Output Current
A
U6-06
Temperature
Drive internal temperature
C
U6-07
Output Torque
Output Torque
N
.
M
U6--30
Standby Para 1 ~ Standby Para 10
Reserve parameters. Some parameter
can be given a meaning when needed.
--
