BL6-U Parallel Integrated Controller Quick Commissioning User Manual
36
Building Setup Parameters List
Para
No.
Display
Content
Range
Factory
Setting
Unit
Live
Change
F0-00
Total Floor
Total floor number (same as door
zone plate number)
2~64
6
--
N
F0-01
Homing Floor
Without landing/car call elevator will
return this floor.
1~
Total Floor
1
--
N
F0-02
Fire Floor
At fire-linkage circuit close, elevator
enter fire mode and return to this
floor automatically.
1~
Total Floor
1
--
N
F0-03
Parking Floor
When close electric lock in the
process of running, elevator return to
this floor and stop.
1~
Total Floor
1
--
N
F0-04
Show Select
Set the output display style:
1: 7-segment Code; 2: BCD Code;
3: Gray Code 4: Point-to-point;
5: Binary
1~5
1
--
N
F0-05

F0-68
Set Indication 1~64
Set indication 1-64, customized
character/figure display available
---
1
…
64
--
N
Running Setup Parameters List
Para
No.
Display
Content
Range
Factory
Setting
Unit
Live
Change
F1-00
Car Speed
Elevator speed at motor rated speed. Calculate
through motor rated rev, traction ratio,
deceleration ratio and traction sheave
diameter.
0~4.0
1.6
m/s
N
F1-01
Motor
Speed
Motor speed at elevator rated speed
(Calculated)
1~9999
306
RPM
N
F1-03
Insp Speed
Car running speed at inspection cannot exceed
0.6m/s based on relevant standards and
regulations
0~0.6
0.3
m/s
Y
F1-04
Start Speed
For large resistance at motor start, the starting
speed can have smooth increase. The start
smooth speed is invalid if set to “0”.
0~0.2
0.03
m/s
Y
F1-05
Leveling
Speed
When elevator park outside door zone due to
fault, if satisfy running condition, the elevator
can level to door zone with this speed.
0.01
~
0.6
0.3
m/s
Y
F1-06
Least Speed
Steady speed on the lowest speed curve.
0~1.0
0.5
m/s
N
F1-07
Open Door
Speed
Car speed when elevator open door in advance
is allowed.
0~0.3
0.15
m/s
N
F1-08
Relevelst
Speed
The speed limit for re-leveling. If speed exceeds
such value in re-leveling process, the re-leveling
will stop with #03 protections.
0~0.3
0.3
m/s
N
F1-09
Relevelrun
Speed
Elevator running speed at re-leveling.
0~0.10
0.05
m/s
N
F1-10
Acceleration
B1
B1 refers to the acceleration speed curve
changing rate, smaller value means elevator
start with smooth and gentle increase of speed.
0.1~1.0
0.5
m/s
2
N
F1-11
Deceleration
B2
B2 refers to the deceleration speed curve
changing rate, smaller value means elevator
brake with smooth and gentle decrease of
speed.
0.1~1.0
0.5
m/s
2
N
F1-12
S Curve P1
P1: Acceleration speed increase rate at
beginning of elevator start; smaller value means
beginning of elevator start with slow and steady
movement.
0.1~1.0
0.5
m/s
3
N
