No-load Compensation Setup Parameters List
Special parameters (FC) are mapping a part of factory parameters (FX) in customer level; users
can access this part information by user level password. In these parameters, FC-00~FC-06 can only
be viewed but not editable, while other parameters can be changed. Special parameters (FC)
number, description and content are shown below.
Special Parameters List
Environment Setup Parameters List
Para
No.
Display
Content
Range
Factory
Setting
Unit
Live
Chang
FA-00
StratKP
Start-up proportional gain with no
compensation.
0~50000
30
--
N
FA-01
StratKI
Start-up integral gain with no
compensation
0~50000
750
--
N
FA-08
PLKP1
No compensation effect
proportional gain 1
1~6500
3600
--
N
FA-09
PLTime
No compensation effect time
1~1000
900
ms
N
FA-11
PLKP2
No compensation effect
proportional gain 2
0~50000
800
--
N
FA-12
PLKPMOD
No compensation effect
proportional factor
0~50000
125
--
N
Para
No.
Display
Content
Range
Factory
Setting
Live
Chang
FC-00
Zpulse_Init
Result of motor angle tuning, same as
FX-00.
0~3277
--
N
FC -07
KpIreg
Current ring proportional (FX-07),
MODIFY WITH CAUTION!
0~65535
10000
N
FC -08
KxIreg
Current ring integral (FX-08), MODIFY
WITH CAUTION!
0~65535
5000
N
FC-13
AutoTuneModeSel
Sine/Cosine PG card auto- tuning
selection (FX-20):
0: Rotation; 1: Stationary;
0/1
0
N
FC-14
N Temp Alarm Ena
Negative temperature alarm (FX-21) 1:
Alarm enable at -15C;
0: Alarm disable at -15C.
0/1
1
N
FC-15
InitTuneEnable
When using Sine/Cosine PG card,
whether need CD signal for position at
power up 0: Yes.1: No (Can only set to 0
for SPG-V33 and above) Set to 0 can
avoid electric noise at first power up.
0/1
0
N
FC-16
CD DirSel
FC15 is available if set to 1. Set to 0 if AB
& CD signal in same phase, otherwise set
to 1. (Auto selected at motor angle
tuning.)
0~3
0
N
Para
No.
Display
Content
Range
Factory
Setting
Live
Chang
A0-00
Language Sel
Language selection
--
English
Y
A0-01
User Password
Input/Setting user level password
000000~
999999
000000
Y
A0-02
Factory Password
Input/setting factory level password
000000~
999999
0000000
Y
A0-04
Contrast
Setting the LCD contrast level
0~10
5
N
