DISASSEMBLY PROCEDURE OF PRODUCT
Below is a brief summary of components and the required parts needed to be disassembled from the unit during replacement or repair.
Component
Removal Parts
Oven Burner Igniters Oven Bottom
Kick Panels (for wire disconnect)
Broiler Burner Igniters None
Oven Thermostat Control Panel
Thermostat bulb shield
Top Grates
Ring Grates
Reignition Spark Module Control Panel RPB/RPBGT
Thermostat Griddle Griddle Plate (Pull wires forward)
Control Panel
Manifold Gas Valves (all) Control Panel
Valve Switches Control Panel
Pressure Regulator Top Grates
Ring Grates
Regulator Shield
Single Thermo-valve: small oven Oven Bottom
Kick Panel (for wire removal)
Single Thermo-valve: Griddle Control Panel
Single Thermo-valve Char-broiler Control Panel
Please note: This is a generic example of parts removal; all models will vary based on the options and configuration of unit.
