6.2 Solar Charging
Connect the solar panels (in series or parallel) to AC70P via the solar charging cable.
When receiving a continuous input of 500W, the AC70P will automatically stop charging
within 2 hours. However, please be aware that the charging time may vary based on
weather conditions, sunlight intensity, panel orientation, and other variables.
Note: Make sure your solar panels meet the following requirements:
Voc: 12V-58V Current: 10A Max. Power: 500W Max.
6.1 AC Charging
Plug the AC70P into a standard wall outlet and start charging. Once it's fully charged,
the AC70P automatically stops charging to prevent overcharging. For a fast charge, you
can enable Turbo Charging in the BLUETTI App, which allows for an 80% capacity in just
45 minutes at an ambient temperature of 25℃ (77 ℉).
AC70P supports four charging methods: AC, solar, car, and generator.
6. Charging
JUST POWER ON 15
EN
